เครื่องยนต์ของเรา ช่วยประหยัดพลังงาน และขับเคลื่อนความสําเร็จของคุณ

|
| Place of Origin: | China |
| ชื่อแบรนด์: | THMotor |
| ได้รับการรับรอง: | UL |
| Model Number: | NEP 256TC |
| Minimum Order Quantity: | 1set |
|---|---|
| ราคา: | USD 300-10000 |
| Packaging Details: | Seaworthy packing |
| Delivery Time: | 30DAYS |
| Supply Ability: | 5000SET/YEAR |
| Power Range: | 1-260hp | Frequency: | 60hz |
|---|---|---|---|
| IP rate: | IP55 | Standard: | UL |
| Mounting: | B3,B5,B35 | Frame: | 140-440 |
| voltage: | 230/460v,575v | Efficiency: | NEMA premium |
| poles: | 2,4,6 | Enclosure: | TEFC |
| Service Factor: | 1.15 | ||
| เน้น: | NEMA premium high slip induction motor,high slip induction motor IP55,High Torque Induction Motor IP55 |
||
| FRAME | AJ | AK | BA | MIN BB |
BC | MAX BD |
NUMBER OF HOLE |
SCREW | DEPTH OF HOLE |
U | AH | R | ES | S |
| 182TC.184TC 213TC.215TC 254TC.256TC 284TC.286TC |
7.250 7.250 7.250 9.000 |
8.500 8.500 8.500 10.500 |
3.50 3.50 4.75 4.75 |
0.25 0.25 0.25 0.25 |
0.12 0.25 0.25 |
9.00 9.00 10.00 |
4 4 4 |
1/2-13 1/2-13 1/2-13 |
0.75 0.75 0.75 |
1.125 1.375 1.625 |
2.62 3.12 3.75 |
0.986 1.201 1.416 |
1.78 2.41 2.91 |
0.250 0.312 0.375 |
| 0.25 | 11.25 | 4 | 1/2-13 | 0.75 | 1.875 | 4.38 | 1.591 | 3.28 | 0.500 | |||||
| 324TC.326TC | 11.000 | 12.500 | 5.25 | 0.25 | 0.25 | 14.00 | 4 | 5/8-11 | 0.94 | 2.125 | 5.00 | 1.845 | 3.91 | 0.500 |
| 365TC | 11.000 | 12.500 | 5.88 | 0.25 | 0.25 | 14.00 | 8 | 5/8-11 | 0.94 | 2.375 | 5.62 | 2.021 | 4.28 | 0.625 |
| 404TC.405TC | 11.000 | 12.500 | 6.62 | 0.25 | 0.25 | 15.50 | 8 | 5/8-11 | 0.94 | 2.875 | 7.00 | 2.450 | 5.65 | 0.750 |
| 444TC.445TC | 14.000 | 16.000 | 7.50 | 0.25 | 0.25 | 18.00 | 8 | 5/8-11 | 0.94 | 3.375 | 8.25 | 2.880 | 6.91 | 0.875 |
ผู้ติดต่อ: Chongqing sales team
โทร: +8613251285880
